Atomos Ninja RAW

Name: Atomos Ninja RAW
Brand: ATOMOS
SKU: AO-ATOMNJRW01
Availability: BackOrder

Categories: Monitoring, Recording Monitors SKU: AO-ATOMNJRW01

£718.80 £599.00 Ex. VAT

Rated 0 out of 5

Order Now - Usually delivered in 2-3 weeks

Description

Atomos Ninja RAW (AO-ATOMNJRW01) is a compact 5″ inch HDR monitor recorder designed for affordable, high-quality capture and precise on-set monitoring across filmmaking, broadcast, and content creation environments.

Its bright 1500?nit HDR touchscreen provides clear visibility indoors and outdoors, while direct HDMI recording captures Apple Pro Res and Pro Res RAW straight from the camera sensor to CFexpress Type B or external USB?C storage for fast, reliable results.

Ninja RAW supports a wide range of professional codecs, including Pro Res RAW, Pro Res RAW HQ, Pro Res LT, Pro Res 422, and Pro Res 422 HQ, and is fully compatible with leading NLEs. USB?C camera control is available for supported models, giving access to key settings such as start/stop, ISO, shutter, aperture, and white balance.

Essential monitoring tools are built in, including EL Zone™ false colour, waveform, vector scope, and focus peaking, while creative features like Onion Skin overlay support frame accurate alignment for VFX, animation, and continuity critical work.

Dual USB?C ports offer flexibility for external storage or optional network adaptors, and the rugged, production ready design ensures dependable performance on set. With flexible power options for both studio and field use, Ninja RAW combines advanced Pro Res RAW recording, professional monitoring, and a bright, portable form factor in a single next generation device.

Features

HDMI & CFexpress 5-inch monitor-recorder with camera control
Super-bright, 1500nit, 5-inch HDR touchscreen display
Capture Apple Pro Res, Pro Res RAW, Avid DNx, or H.265 to CFexpress Type B or external USB?C storage
Supports ProRes RAW, ProRes RAW HQ, ProRes LT, ProRes 422, and ProRes 422 HQ
Compatible with leading NLEs including DaVinci Resolve, Adobe Premiere Pro, Final Cut Pro, and Avid Media Composer
USB?C camera control for supported models, including start/stop, ISO, shutter, aperture, white balance, and touch?to?focus
Professional monitoring tools including EL Zone™ false colour, focus peaking, waveform, vectorscope, and more
Onion Skin overlay for frame comparison and precise shot alignment
Dual USB?C ports for external storage or optional network adaptor (sold separately)
Rugged, production? ready design
Flexible power options: NP?F batteries, USB?C power banks, or DC input

Comes With

Ninja RAW monitor-recorder
USB-C locking cable adaptor
HDMI locking cable adaptor
USB-C locking cable (45cm)
Quick Start Guide

Additional information

BRAND	ATOMOS
SCREEN SIZE	5" Inch

Delivery

Please note, for next-day shipping options the product must show in stock in the product status and be before the cut-off period. If the product does not show in stock most items will give an approximate lead time.

Collection
Free Collection is available at our showroom in Hampton, please select this option at the payment stage at the checkout. Please allow one hour to pick and prepare your order for you so it is ready for you when you arrive. Collections must be made at our office during the hours of 9 am to 5:30 pm (Mon to Thurs) and 9 am to 5 pm (Friday).

Standard Delivery
Standard delivery costs £5.99 including VAT and will be sent out by Royal Mail, DPD or APC, this service can take 3-5 working days.

FREE UK Delivery On Orders Over £300 Ex. VAT
We offer FREE standard delivery on all orders over £300 Ex VAT to the UK mainland. Mon-Fri working days only. Saturday deliveries are not guaranteed.

Next Working Day Delivery
UK mainland orders placed before 2 pm will be dispatched the same day for next-day delivery. To qualify for next-day delivery orders must be placed before 2 pm Mon – Thur. Orders placed after 2 pm Thursday will be dispatched Friday for Monday delivery, excluding Bank Holidays. The charge for this service is £12.00 plus VAT. This service is only available for products that are in stock.

Saturday Delivery
Order before 2pm on Friday for Saturday deliveries. Saturday delivery cost £27.50 including VAT – this is only for the UK mainland.

*Excluding all Battery Generators*

Worldwide Shipping

At BPS we can arrange shipping worldwide on most of our products. Please contact sales@bps-tv.co.uk and provide details of the products you are interested in, billing and delivery address, and any company information. Our sales team will then arrange for a full quotation to be provided.

Specification

PRODUCT INFORMATION
Product Name	Ninja RAW
Main Category	Monitor-recorder
Secondary Category	On-camera accessory
Part Code / SKU	ATOMNJRW01
UPC	814164023399
EAN	0814164023399
MSRP (excluding local sales taxes)
Ninja RAW	USD-US $699 / USD-ROW $699 / EUR €599 / GBP £599 / AUD $999
Key Features
1	Super-bright, 1500nit, 5-inch HDR touchscreen display
2	Camera control – manage start/stop, ISO, shutter, aperture, white balance
3	Record in Apple ProRes or ProRes RAW direct from the camera sensor to CFexpress Type B media or external USB-C storage
4	Supports ProRes RAW, ProRes RAW HQ, ProRes LT, 422 & 422 HQ
5	File-compatible with all leading NLEs, including DaVinci Resolve, Adobe Premiere Pro, Apple Final Cut Pro, Avid Media Composer
6	Full suite of professional monitoring tools, including EL Zone™ false color, focus peaking, waveform & more
7	Includes unique tools like Onion Skin overlay to compare frames or align shots
8	2 x USB-C ports for external storage, or network adaptor (*sold separately)
9	Rugged and reliable – built for real-world production environments
10	Super mobile – runs on NP-F batteries, USB-C power banks, or DC adaptor
Description
Positioning / tagline	Monitor. Control. Record.
Product title - short option	Ninja RAW: 5-inch HDMI monitor-recorder, camera control & CFexpress
Product title - long option	Ninja RAW: ProRes/ProRes RAW monitor-recorder with camera control for HDMI & mirrorless cameras
Short description	HDMI & CFexpress 5-inch monitor-recorder with camera control
Long description	Ninja RAW combines HDMI I/O, 1500nits HDR touchscreen, Apple ProRes/RAW recording to ultra-fast CFexpress or external USB media, with a full suite of professional monitoring tools, and camera control/touch to focus for supported cameras. Ideal for content creators with HDMI DSLRs and mirrorless cameras.
Product Specifications
Dimensions (W x H x D mm)	151mm x 92mm x 36mm
Weight	400gms
Mount points	1 x anti-rotation 1/4-inch & 3/8-inch, top and bottom
Environmental
Ambient operating temperature	Up to 40 degrees Celsius
Construction
Body	Aluminium with ABS plastic
Cooling	Actively controlled fan and heat sink
Power
Input voltage	6.2V to 16.8V DC
Operating power	Up to 30W
Multi-function button	Power / lock screen
Continuous power	Via NP-F battery or USB-C PD Power
DC in connector	Via Battery Eliminator (optional)
DTAP	Up to 13W
USB PD IN	45W capable, power supply required
USB PD OUT	Up to 13W
Display
Size	5.2-inch
Resolution	1920 x 1080
Backlight Type	Edge lit
Brightness (cdm2 / Nits)	1500
Aspect ratio	16:9
Color Gamut	Rec.709
Calibration support	Calibrite Display Pro or Display Plus on PC/Mac with Atomos LANC cable (ATOMCAB018, sold separately)
Color Pipeline
Gamma	Sony SLog / SLog2 / SLog3 / HLG, Canon C-Log / C-Log2 / C-Log3, ARRI Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320, / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic V-Log / HLG, JVC J-Log, Red RedLogFilm / Log3G10 / Log3G12, FujiFilm F-Log, PQ (HDR10), HLG, Nikon N-Log
Gamut	BT.2020, DCI P3, DCI-P3 D65, Rec709. Sony: S-Gamut / S-Gamut3 / S-Gamut3.cine / BT.2020 / Rec.709. Canon Cinema: DCI P3 / DCI P3plus / Rec.709. Panasonic: V Gamut. ARRI: Alexa Wide Gamut. JVC: LS300. RED: DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut
3D LUT Display	.Cube format
3D LUT Down Stream	Loop out
3DLUT 50/50	Yes
Monitoring Modes	Native / HLG / PQ / 3D LUT
HDR Output Conversion	Log / HDR to HLG / PQ
Video Input
HDMI	1 x HDMI (2.0) up to 6Kp30
Locking port	Optional
Wi-Fi	No
USB	2 x USB-C 2.0/3.0
Bit Depth	8/10-bit video
Video Chroma Subsampling	4:2:2
Video Output
HDMI	1 x HDMI (2.0) up to 6Kp30
Locking port	Optional
Wi-Fi	No
USB	2 x USB-C 2.0/3.0
Bit Depth	8/10-bit video
Video Chroma Subsampling	4:2:2
Metadata
HDMI	RAW - white balance, exposure index, shutter speed/angle, Iris F stop, ISO, gamma, gamut
Network
USB	2 x USB-C 2.0/3.0
Connectivity
Bluetooth	No
LANC	Yes
Audio In/Out
HDMI	8-channel, 24-bit
Analogue Audio Line In	3.5mm headphone jack, 2-channel input
Headphone Out	3.5mm headphone jack, 2-channel
Timecode
Embedded	HDMI
Time of day	Yes
Reference / Genlock input	No
LTC	No
Wireless AirGlu RF Server and Client	No
Wireless AirGlu BT Server	No
Resolution & Frame Rates (Record, Monitor & Playback)
RAW	Up to 6Kp30
4K DCI	23.98/24/25/29.9/30/50/59.94/60p
4K UHD	23.98/24/25/29.9/30/50/59.94/60p
2K DCI 2048 x 1080	Yes
1080p	23.98/24/25/29.9/30/50/59.94/60/100/120p
1080 PsF	Converted to P and looped out PsF
1080i	50/59.94/60i
720p	50/59.94/60p
Supported Media
CF Express	Atomos certified CF Express Type B media
USB	Atomos certified USB 3.0 media
File System	ExFAT
Codecs
Apple ProRes RAW	ProRes RAW, ProRes RAW HQ
Apple ProRes	LT, 422, 422 HQ
Avid DNxHD	DNxHD 220x, 220, 145, 36
Avid DNxHR	LB, SQ, HQ, HQX
H.265	LQ, MQ, HQ, XQ in 8/10-bit, 4:2:2 and 4:2:0
Playback
Playlist	Yes - create customer playlists from full or sub-clips
Loop	Yes - with user-customizable in/out markers
Apple ProRes RAW	Yes - recorded clips
Apple ProRes	Yes - with linear PCM audio
Avid DNx	Yes - with linear PCM audio
H.265	Yes
Recording
Pre-roll	ProRes, DNxHD only
Timelapse	Yes
Simultaneous Proxy Record	Yes
On-screen Monitoring Tools
Waveform	3 sizes – adjustable opacity & brightness
RGB parade	3 sizes – adjustable opacity & brightness
Vectorscope	2 sizes – adjustable opacity & brightness
1 x Zoom	Yes. 1:1 pixel mapping for 4K
2 x Zoom	Yes
Focus peaking	Colour selected / threshold setting / colour / mono / edges only
Atomos False Color	Yes, with scale
ARRI False Color	Yes
EL Zone	Yes
Zebra	Yes, adjustable
Isolate color channel	Blue only
Cine Frame Guides	Presets for 2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3
Social Frame guides	Presets for 9:16, 1:1, 191:1, 4:5
Onion Skin	Yes
Safe areas	Action and graphic
Grid markers	9 grid
Anamorphic desqueeze	1.25x, 1.33x, 1.5x, 1.6x, 1.65x, 1.79x, 1.8x, 2x
Display Flip	Vertical only
Onboard Signal Processing
Pulldown removal	24 / 25 / 30 pSF > 24 / 25 / 30p (2:2 pulldown), 60i > 24p (3:2 pulldown)
4K UHD downscale for HD	Loop out - 4K UHD to HD
DCI Crop	Loop out - 17:9 to 16:9 crop
Remote Control
HDMI	Auto HDMI trigger, supported protocols - Canon, Sony, Atomos
Serial 2.5mm Jack	Calibration via optional USB to serial cable
AirGlu BT	No
AirGlu RF	No
Camera Control
USB-C	Start/stop recording, ISO, shutter, aperture, frame rate, touch to focus (with supported cameras)
What’s in the Box
Accessories included	Ninja RAW monitor-recorder, USB-C locking cable adaptor, HDMI locking cable adaptor, USB-C locking cable (45cm), Quick Start Guide.
Box dimensions (W x H x D mm)	190mm x 130mm x 75mm
Box weight	665gms
Warranty
Standard	1 year. Extended to 2 years on product registration (excludes screen).
