| Type | 22.3 x 14.9mm CMOS |
| Effective Pixels | Approx. 24.1 megapixels |
| Total pixels | Approx 25.8 megapixels |
| Aspect Ratio | 3:2 |
| Low-Pass Filter | None |
| Sensor Cleaning | None |
| Colour Filter Type | RGB Primary Colour |
| Sensor Shift-IS | No |
|
| Type | DIGIC 8 |
|
| Lens Mount | RF |
| Lens Compatibility | RF, RF-S (EF and EF-S lenses compatible via mount adapter)*1 |
| Focal Length | Equivalent to 1.6x the 35mm focal length of the lens |
| In Body Image Stabilisation | Not Provided |
| Image Stabilisation | Optical stabilisation with lenses featuring IS Movie Digital IS: Off / Enabled / Enhanced*2 |
|
| Type | Dual Pixel CMOS AF System Contrast detection method is used during 4K Movie Servo AF |
| AF System/Points | Stills: Maximum 3975 positions Video: Maximum 3375 positions Maximum 143/99 points available for automatic selection in Face+Tracking mode. May vary depending on settings. Max 25 frames in Zone AF*1 Freely position 1 AF point/ 1 AF Zone via manual selection (area available lens dependent) |
| AF working range (stills / movies) | EV -4 - 18 / EV -2 - 18*3 |
| AF Modes | One-Shot AF and Servo AF |
| AF Point Selection | Face+ Tracking Spot AF 1-point AF Zone AF Stills: Maximum 3975 positions Video: Maximum 3375 positions Maximum 143/99 points available for automatic selection in Face+Tracking mode. May vary depending on settings. Max 25 frames in Zone AF*1 Freely position 1 AF point/ 1 AF Zone via manual selection (area available lens dependent) |
| AF Tracking | Humans (Eyes/Face/Head/Body) |
| AF Lock | Locked when shutter button is pressed half way or customisable AE Lock Button |
| AF Assist Beam | via LED assist beam |
| Manual Focus | With RF lenses: Via dedicated AF/MF switch on lens where available, or in menu With EF & EF-S lenses - Select via AF/MF switch on lens MF Peaking available AF+MF available (Manual focus adjustment after One-Shot AF) Magnify image available during MF (3-10x, in 0.1x increments)*4 |
|
| Metering modes | Real-time metering from the image sensor (1) Evaluative metering (384 zones, 24x16) (2) Partial metering at center (approx. 5.8% of Live View Screen)- stills only (3) Center weighted average metering (4) Spot metering (approx. 2.9% of Live View Screen) Partial and spot metering not available in movie |
| Metering Range | Still image: EV -2 - 20*5 Movie: EV 0 - 20 |
| AE Lock | Auto: In One-shot AF mode, exposure is locked as soon as subjects are in focus Manual: By AE lock Button in creative zone or movie modes |
| Exposure Compensation | +/-3 EV in 1/3 stop increments |
| AEB | 3 shots, +/- 2 EV, 1/3-stop increments |
| Anti-Flicker Shooting*6 | Yes. Flicker detected at a frequency of 100 Hz or 120 Hz High frequency anti-flicker shooting not provided |
| ISO Sensitivity | Normal ISO speed: ISO 100- 12800 in 1/3 or 1-stop increments Expanded ISO speed: H (equivalent to ISO 25600)*7 |
|
| Type | Electronically controlled focal-place shutter (Rolling shutter, using the image sensor*9. Electronic first curtain, mechanical 2nd curtain*8 |
| Speed | 30 - 1/4000 sec (1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode) |
| Shutter Release | Soft-touch electromagnetic release |
|
| Type | Auto white balance with the imaging sensor |
| Settings | AWB (Ambience priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting White balance compensation: 1. Blue/Amber +/-9 2. Magenta/Green +/-9*10 |
| Custom White Balance | Yes, select an image on a card for use as a custom white balance |
| WB Bracketing | +/- 3 levels, single level increments*11 |
|
| Type | 0.39-type OLED Electronic Viewfinder |
| Dot Count | Approx. 2,360,000 dots |
| Coverage (Vertical/Horizontal) | Approx 100%*12 |
| Magnification | Approx. 0.95x*13 |
| Eyepoint | Approx 22mm*14 |
| Dioptre Correction | Approx. -3.0 to +1.0 m-1 (dpt) |
| Viewfinder Information | Viewfinder sensor: provided Vertical display for Stills only. Exposure Simulation*15 'Customisable and toggle via [INFO] Button*16 (1) Liveview image with exposure info (2) Liveview image with basic info (3) Liveview image with full info Customisable settings: Grid overlay (x3 formats), Histogram (Brightness/ RGB) Viewfinder Brightness: Manually adjustable 1-5 |
| Depth of field preview | Yes |
| Eyepiece Shutter | No |
|
| Type | 7.5 cm (3.0”) LCD (TFT). 3:2 aspect ratio. Approx. 1,040,000 dots. |
| Coverage | Approx 100% |
| Brightness Adjustment | Adjustable to one of seven levels |
| Touch-Screen Operations | No |
| Display Options | Customisable and toggle via [INFO] Button*16 (1) Liveview image with exposure info (2) Liveview image with basic info (3) Liveview image with full info Customisable settings: Grid overlay (x3 formats), Histogram (Brightness/ RGB) |
|
| Built-in Flash GN (ISO 100, meters) | 6 |
| Built-in Flash Coverage | Approx. 18mm angle of view |
| Built-in Flash recycle time | Approx. 5 seconds |
| Modes | Auto Fire Off E-TTL II flash metering (Evaluative (Face Priority) / Evaluative / Average) |
| Red-Eye Reduction | Yes |
| X-sync | 1/250 sec |
| Flash Exposure Compensation | +/- 2 EV in 1/3 increments |
| Flash Exposure Bracketing | No |
| Flash Exposure Lock | Yes |
| Second Curtain Synchronisation | Yes*17 |
| HotShoe | 5-pin shoe only |
| External Flash Compatibility | E-TTL II with EX and EL series Speedlites, wireless multi-flash support*18 |
| External Flash Control | Via camera setting/ flash setting menu |
|
| Modes | Stills: Scene Intelligent Auto Hybrid Auto SCN Special Scene Modes (x10) - Portrait - Landscape - Sports - Panning - Close-up - Food - Night Portrait - Handheld Night Scene - HDR Backlight Control - Silent shutter mode19 Creative Filters - Grainy B/W - Soft focus - Fish-eye effect - Water painting effect - Toy camera effect - Miniature effect - HDR art standard - HDR art vivid - HDR art bold - HDR art embossed20 P (Program AE) Tv (Shutter-priority AE) Av (Aperture-priority AE) M (Manual exposure, bulb exposure) Movies: Movie auto exposure Movie manual exposure |
| Picture Styles | Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3) |
| Colour Space | sRGB and Adobe RGB |
| Image Processing | Highlight Tone Priority (standard and enhanced) Auto Lighting Optimizer (4 settings) Long exposure noise reduction High ISO speed noise reduction (4 settings + Multi Shot NR) Lens peripheral illumination correction Chromatic aberration correction Diffraction correction Digital Lens Optimizer (DLO) Creative Assist: Presets Background Blur (5 settings) Brightness (19 levels) Contrast (9 levels) Saturation (9 levels) Colour Tone 1 & 2 (19 levels) Monochrome (Off/Black and white/Sepia/Blue/Purple/Green) |
| Drive modes | Single Shooting Continuous Shooting Self-timer: 10 sec. / remote control Self-timer: 2 sec. / remote control Self-timer: continuous shooting |
| Continuous Shooting | One shot AF: Max. Approx. 6.5 shots/sec with Electronic 1st-curtain shutter, speed maintained for 97 JPEG(All sizes) or 6 RAW, 17 C-RAW, or RAW + L JPEG: 6, C-RAW + L JPEG: 13 images.21 Servo AF: Max. Approx. 3.5 shots/sec. |
| Interval Timer | No |
|
| Still Image Type | JPEG: 8 bits, Standard / Fine: (Exif 2.31 compliant) / Design rule for Camera File system (2.0) RAW: RAW, C-CRAW (CR3 14 bits) Digital Print Order Format [DPOF] Version 1.1 compliant*22 |
| RAW+JPEG simultaneous recording | Yes, RAW + various JPEG compression possible |
| Image Size | RAW / C-RAW: 24.0 megapixels (6000 x 4000) JPEG 3:2: L 24 megapixels (6000 x 4000) M 10.6 megapixels (3984 x 2656) S1 5.9 megapixels (2976 x 1984) S2 3.8 megapixels (2400 x 1600) JPEG 4:3: L 21.3 megapixels (5328 x 4000) M 9.5 megapixels (3552 x 2664) S1 5.3 megapixels (2656 x 1992) S2 3.4 megapixels (2112 x 1600) JPEG 16:9: L 20.2 megapixels (6000 x 3368) M 8.9 megapixels (3984 x 2240) S1 5.0 megapixels (2976 x 1680) S2 3.2 megapixels (2400 x 1344) JPEG 1:1: L 16.0 megapixels (4000 x 4000) M 7.1 megapixels (2656 x 2656) S1 3.9 megapixels (1984 x 1984) S2 2.6 megapixels (1600 x 1600)23 |
| Folders | New folders can be created and selected |
| File Numbering | (1) Continuous, Auto Reset (2) Manual Reset |
|
| Movie Type | MP4: MPEG-4 AVC/H.264, Audio: AAC |
| Movie Size | 4K UHD- 3840 x 2160, 23.98 / 25 fps, IPB (Standard), AAC Full HD - 1920 x 1080, 59.94 / 50 / 29.97 / 25 / 23.98 fps, IPB (Standard), AAC HD- 1280 x 720, 59.94 / 50 fps, IPB (Standard), AAC High Frame Rate movies- 1280 x 720, 119.88 / 100 fps, IPB (Standard), No audio Time-lapse movied- 3840 x 2160 / 1920 x 1080, 29.97 / 25 fps, All-I, No audio Miniature effect movies- 1920 x 1080, 29.97 / 25 / 23.98 fps, IPB (Standard), No audio*24 |
| Colour Sampling (Internal recording) | 4K / Full HD: YCbCr4:2:0 8-bit |
| Canon Log | Not supported |
| Movie Length | Max duration 29min 59sec Max file size: SDXC: exFAT: Unlimited SDHC: FAT32: 4 GB SD: FAT16 / FAT12: 2GB |
| High Frame Rate Movie | HD 1280 x 720, at 100 or 119.88 fps Recorded aa 1/4 speed slow motion movie |
| Frame Grab | 8.3-megapixel JPEG still image frame grab from 4K UHD movie possible |
| Bitrate/Mbps | 4K UHD (23.98, 25 fps): IPB (Standard) 120 Mbps Full HD (59.94, 50 fps): IPB ( Standard) 60 Mbps Full HD (29.97, 23.98, 25 fps): IPB (Standard) 30 Mbps HD (59.94, 50 fps): IPB (Standard) 26 Mbps HFR movies (119.88, 100 fps): IPB (Standard) 52 Mbps 4K time-lapse (29.97, 25 fps): ALL-I 300 Mbps Full HD time-lapse (29.97, 25 fps): ALL-I 90 Mbps Miniature effect (29.97, 23.98, 25 fps): IPB (Standard) 30 Mbps |
| Dual Card Recording | Not supported |
| Microphone | Built-in monaural microphone (48 KHz, 16-bit x 2 channels) |
| HDMI Display | Output to external monitor only (output of images and shooting information, images/video are recorded to the card) Camera screen and External Monitor output (Recording to camera is not possible, use with external recorder, camera screen shows images with shooting information) |
| HDMI Output | HDMI Micro OUT terminal (Type D) Auto: - 4K (UHD): NTSC (23.98), PAL (25.00p) - 1080 NTSC (59.94p / 59.94i), PAL (50.00p / 50.00i) - 480 NTSC (59.94p) - 576 PAL (50.00p) 1080p: - 1080 NTSC (59.94p / 59.94i), PAL (50.00p / 50.00i) - 480 NTSC (59.94p) - 576 PAL (50p) |
| Focusing | 4K: Contrast detection AF Full HD: Dual Pixel CMOS AF HFR Movie: Autofocus disabled ISO Auto: 100-12800, H: 25600 Manual: 100-12800, H: 25600 |
|
| Custom Functions | ISO Expansion Safety shift 7 customisable buttons - Shutter button (half press) - Exposure compensation button - AE lock button - ISO speed setting button - Flash button - Movie shooting button - Drive mode button Release shutter without lens Retract lens on power off |
| Metadata Tag | User copyright information (Author's Name, Copyright Details) Image rating (0-5 stars) |
| LCD Panel / Illumination | No |
| Water/ Dust resistance | No |
| Sound Memo | No |
| Intelligent Orientation Sensor | No |
| Playback zoom | 1.5x - 10x in 15 levels |
| Playback Display Formats | (1) Single image with information (toggle options) (2) Single image (3) Index display (4/9/36/100 images) |
| Slide Show | Playback time: 1/2/3/5/10/20 seconds Repeat: Enable / Disable Transition Effects: Off, Slide in 1-2, Fade 1- 3 Background music: Off / On |
| Histogram | Brightness/ RGB |
| Highlight Alert | Yes*25 |
| Image Erase | Single image, select range, Selected images, Folder, Card |
| Image Erase Protection | Erase: Single image, Selected images, Selected range, folder, All images on card , All found images Protection: Selected images, Selected range, All images. Folder |
| Self Timer | 2 sec, 10 sec |
| Menu Categories | (1) Shooting menu (2) Playback menu (3)Communication features menu (4) Function settings menu (5) Display level settings menu (6) My Menu |
| Menu Languages | 29 Languages English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Vietnamese, Indonesian, Hindi, Japanese |
| Firmware Update | Firmware update possible by the user via SD card, EOS Utility or Camera Connect app |
|
| Computer | Hi-Speed USB (USB 2.0), USB Type-C terminal |
| Wi-Fi | Wireless LAN (IEEE802.11b/g/n) (2.4 GHz), with Bluetooth 4.2 support Features supported - EOS Utility, Smartphone, Upload to image.canon, Wireless printing |
| Other | HDMI (Micro - Type-D connector), HDR output to compatible TV supported External microphone in (3.5mm stereo mini jack) |
|
| Canon Printers | Canon Compact Photo Printers and PIXMA Printers supporting PictBridge |
| PictBridge | PictBridge-compatible (wireless LAN) printer compatible |
|
| Type | SD, SDHC, SDXC (UHS-I compatible) |
| PC & Macintosh | See support pages for up- to-date information |
|
| Image Processing | Digital Photo Professional |
| Other | Picture Style Editor, EOS Utility, Image Transfer Utility Camera Connect app available on iOS and Android devices |
|
| Batteries | 1 x Rechargeable Li-ion Battery LP-E17 |
| Battery life | Viewfinder: Approx. 340 shots (Based on CIPA standards) Live view: Approx 430 shots (Based on CIPA standards) 4K Movie Recording: Approx. 110 mins Full HD Movie Recording: Approx 160 mins Playback time when playing back a slideshow of still images: Approx. 190 mins (With a new, fully charged LP-E17) |
| Battery Indicator | 4 levels |
| Power saving | Display off (15, 30 sec or 1, 3, 5, 10, 30 mins) Auto Power Down (30 sec or 1, 3, 5, 10 mins, Disable) Viewfinder off (1, 3 min, disable) Power saving mode |
| Power Supply & Battery Chargers | Battery charger LC-E17E AC adapter AC-E6N DC Coupler DR-E1826 |
|
| Wireless File Transmitter | Not compatible |
| Cases / Straps | Protecting cloth PC-E1 / PC- E2 Strap provided |
| Lenses | RF and RF-S lenses EF and EF-S lenses compatible via adapter EF-M lenses not compatible*27 |
| Lens Adapters | Mount Adapter EF-EOS R, Drop-in Filter Mount Adapter EF-EOS R*28 |
| Flash | EL series Speedlites: EL-1 / EL-100 EX series Speedlites / Macrolite Speedlite Transmitter ST-E3-RT (Ver. 2) / ST-E3- RT / ST-E2 Off-Camera shoe cord OC-E3*29 |
| Remote Controller / Switch | Bluetooth Remote BR-E1 Tripod grip HG-100TBR Remote Switch RS-60E3*30 Other Interface cable IFC-100U Interface cable IFC-400U Mount Adapter EF-EOS R |
|
| Body Materials | Mainly polycarbonate resin with glass fibre that incorporates an aluminium alloy |
| Operating Environment | 0 – 40 °C, 85% or less humidity |
| Dimensions (WxHxD) | 116.3 x 85.5 x 68.8mm |
| Weight (body only) | Approx. 356 g*31 |
| Notes | [1] RF 5.2mm F2.8L DUAL FISHEYE and RF 85mm F1.2L USM DS are not compatible [2] When using Movie Digital IS, the movie will be cropped [3] When using an f/1.2 lens (except RF lenses with a DS coating) with the center AF point and One-Shot AF at room temperature and ISO 100 [4] When lenses with a focus mode switch are used, the setting on the lens takes precedence [5] At room temperature, ISO 100 [6] Not available when using the electronic shutter Flicker can also be detected manually Increases shutter-release time lag May decrease continuous shooting speed The interval between shots in continuous shooting may vary Colour tone may not match the colour tone of images captured with this feature set to [Disable] Changing light source conditions during continuous shooting may revent reduction of the effects of flicker [7] When set to [Highlight tone priority], the available manual setting range is ISO 200-12800 [8] Not available in silent shutter mode [9] When using rolling shutter, distortion can occur When using silent shutter, RAW/C-RAW is processed with 12-bit A/D conversion [10] Shifted from the colour temperature of the current WB mode Blue / Amber and Magenta / Green can be set at the same time Cannot be used in conjunction with WB bracketing [11] WB shift cannot be used in conjunction with WB bracketing [12] At JPEG Large image quality, a 3:2 aspect ratio and approx 22mm eyepoint [13] 3:2 aspect ratio, with 50mm lens focussed at infinity, -1m-1 [14] At -1m-1 from eyepiece lens end [15] Depth of field (aperture setting) is not applied [16] Applies to both viewfinder and screen [17] First curtain synchronisation is used with shutter speeds faster than 1/60 sec. [18] Not compatible with accessories designed for multi-function shoes [19] Brightness can be set except in HDR Backlight Control mode Panning- effect can be set Min / Med / Max Food- Five levels of colour tone (Cool <--> Warm) can be set Handheld Night Scene- Flash photography with the built-in flash is not available Silent shutter mode- The camera may make sounds for operations such as autofocusing, aperture adjustment and image stabilisation. Flash photography is not available [20] Only JEGs can be captured in Creative filters mode [21] Number of shots using a UHS-I compliant 32GB card that conforms to Canon testing standards Maximum burst as measured under conditions conforming to Canon testing standards (continuous shooting in One-Shot AF mode, ISO 100, and Standard Picture Style Maximum burst varies depending on shooting conditions includig aspect ratio, subject, memory card brand, ISO speed, Picture Style and Custom Functions etc. Setting Auto Lighting Optimizer to [High] reduces maximum burst [22] When using continuous shooting in silent shutter mode, 12-bit A/D conversion is applied to RAW files [23] Maximum burst as measured under conditions conforming to Canon testing standards (continuous shooting in One-Shot AF mode, ISO 100, and Standard Picture Style) [24] When resolution is 3840 x 2160, image is cropped around the centre of the image sensor Digital zoom is only available when using Full HD at 29.97 / 25 / 23.98 fps For High Frame Rate movies, Time-lapse movies and Miniature effect movies, sound recording, Movie Servo AF, Movie digital IS and Movie auto slow shutter are disabled For High Frame Rate movies and Time- lapse movies, AF is disabled during recording High Frame Rate movies frame rate shown is recording frame rate Time-lapse movies frame rate shown is playback frame rate [25] Available in detailed information display only [26] Charging and powering the camera via USB is not supported [27] Operation of the RF 5.2mm dual fisheye lens, RF 85mm F1.2L USM DS and RF Extenders is not guaranteed [28] Control Ring mount adapter control ring will not operate [29] Accessories using the 21-pin multi- function shoe are not compatible [30] When using tripod grip HG-100TBR the total weight including camera, lens, microphone and other accessories should not exceed 1 kg [31] Based on CIPA guidelines, including battery and card |
|
| Image Size | APS-C |
| 35mm Film Equivalent Focal Length (mm) | 29-72mm |
| Angle of View(Horzntl, Vertl, Diagnl) | 64°30'-28°20', 45°30' -19°05', 74°20'-33°40' |
| Lens Construction (Elements/Groups) | 7/7 |
| Special Optics | 2 x PMoAspherical |
| Number of Diaphragm Blades | 7 |
| Minimum Aperture | 22 @ 18mm / 32 @ 45mm |
| Closest Focusing Distance (m) | 0.2 (18mm) (Manual Focus: 0.15) 0.3 (35mm) (Manual Focus: 0.24) 0.35 (45mm) (Manual Focus: 0.25) |
| Maximum Magnification (x) | 0.14 (18mm) (Manual Focus: 0.25) 0.15 (35mm) (Manual Focus: 0.21) 0.16 (45mm) (Manual Focus: 0.26) |
| Control Ring | Combined Focusing/Control |
| Image Stabilizer OIS1 | 4 |
| Image Stabilizer IBIS x OIS1 | 6.5 |
| AF Actuator | STM |
| Coatings | Super Spectra |
| Fluorine | No |
| Lens Cap | E-49 |
| Lens Hood | EW-53 |
| Lens Case/Pouch | LP814 |
| Rear End Cap | Lens Dust Cap RF |
| Magnification with Extension Tube EF12 II | Not compatible |
| Magnification with Extension Tube EF25 II | Not compatible |
| Extender Compatibility | Not compatible |
| Extension Tubes | Not compatible |
| Dust/Moisture Resistance | No |
| Exterior Coating | - |
| Filter Diameter (mm) | 49 |
| Max. Diameter x Length (mm) | 69 x 44.3 |
| Weight (g) | 130 |
