Panasonic AW-UE150A 4K PTZ Camera – Black

Name: Panasonic AW-UE150A 4K PTZ Camera - Black
Brand: PANASONIC
SKU: AW-UE150AKEJ
Availability: BackOrder

Categories: Cameras, PTZ Cameras SKU: AW-UE150AKEJ

£8,340.00 £6,950.00 Ex. VAT

Rated 0 out of 5

Order Now - Usually delivered in 3-5 days

Description

Panasonic AW-UE150A 4K PTZ Camera – Black (AW-UE150AKEJ) has been designed to meet the needs of professional broadcasters and content creators, delivering advanced video quality, operability and efficiency in studio-based video productions.

The UE150A supports the NDI^® High Bandwidth* protocol, enabling seamless IP-based, low-latency 4K video transmission. This is in addition to existing support for SRT and NDI^®HX2 protocols, ensuring steady performance in unstable network conditions.

It is also compatible with 12G-SDI, 2x 3G-SDI, HDMI, and fibre output formats. This enables the UE150AW/AK to be easily integrated into a variety of on-site production systems, making it the perfect choice for both remote production and live streaming environments.

Exceptional performance and high-quality video

Equipped with a high-sensitivity 1.0-type 4K MOS sensor, Panasonic’s UE150AW/AK delivers high quality video. Its wide-angle lens (75.1° horizontal), 20x optical zoom, and built-in auto-tracking functionality make it the ideal choice for a versatile range of installations.

The UE150AW/AK features an optical low-pass filter (OLPF) that reduces luminance and colour moiré when filming monitors or LED walls, whilst HDR (HLG) compatibility delivers true-to-life image reproduction.

Its enhanced Optical Image Stabilizer (OIS) minimises image shake during pan and tilt operations, and upgraded synchronisation of pan, tilt and zoom presets for a smoother camera operation.

Increased compatibility for any environment

The UE150AW/AK is compatible with Panasonic’s AK-HRP1010GJ/HRP1015GJ Remote Operation Panel for seamless colour matching with studio cameras, increasing overall versatility and functionality within broadcasting setups

Summary

Comes With

1x Panasonic AW-UE150A 4K PTZ Camera – Black
1x Mounting Plate

Delivery

Please note, for next-day shipping options the product must show in stock in the product status and be before the cut-off period. If the product does not show in stock most items will give an approximate lead time.

Collection
Free Collection is available at our showroom in Hampton, please select this option at the payment stage at the checkout. Please allow one hour to pick and prepare your order for you so it is ready for you when you arrive. Collections must be made at our office during the hours of 9 am to 5:30 pm (Mon to Thurs) and 9 am to 5 pm (Friday).

Standard Delivery
Standard delivery costs £5.99 including VAT and will be sent out by Royal Mail, DPD or APC, this service can take 3-5 working days.

FREE UK Delivery On Orders Over £250
We offer FREE standard delivery on all orders over £250 Ex VAT to the UK mainland. Mon-Fri working days only. Saturday deliveries are not guaranteed.

Next Working Day Delivery
UK mainland orders placed before 2 pm will be dispatched the same day for next-day delivery. To qualify for next-day delivery orders must be placed before 2 pm Mon – Thur. Orders placed after 2 pm Thursday will be dispatched Friday for Monday delivery, excluding Bank Holidays. The charge for this service is £12.00 plus VAT. This service is only available for products that are in stock.

Saturday Delivery
Order before 2pm on Friday for Saturday deliveries. Saturday delivery cost £27.50 including VAT – this is only for the UK mainland.

*Excluding all Battery Generators*

Worldwide Shipping

At BPS we can arrange shipping worldwide on most of our products. Please contact sales@bps-tv.co.uk and provide details of the products you are interested in, billing and delivery address, and any company information. Our sales team will then arrange for a full quotation to be provided.

Specification

General
Power Requirements	DC12 V (10.8 V to 24.0 V)
PoE	IEEE802.3 bt standard: DC42 V to 57 V (software authentication (LLDP) is supported)
Current Consumption	4.0 A (XLR IN connector), 1.2 A (PoE++ power supply)
Ambient Operating Temperature	0 °C to 40 °C (32 °F to 104 °F)
Ambient Operating Humidity	20 % to 90 % (no condensation)
Storage Temperature	–20 °C to 50 °C (–4 °F to 122 °F)
Weight	Approx. 4.3 kg (9.48 lbs) (excluding mount bracket)
Dimensions	213 mm x 267 mm x 219 mm (8-3/8 in x 10-1/2 in x 8-5/8 in) (excluding protrusions, cable cover, direct ceiling mount bracket)
Finish	AW-UE150AW: Pearl white / AW- UE150AK: Black
Controller Supported	AW-RP150GJ, AW‑RP60GJ, AK-HRP1010GJ, AK-HRP1015GJ, AK-HRP1000GJ, AK‑HRP1005GJ, AK‑HRP250GJ
Camera Unit
Imaging Sensor	1-type 4K MOS x1
Effective Pixels	Approx. 20,180,000 pixels
Zoom	Optical zoom: 20x
Zoom	i.Zoom: UHD 24x, FHD 32x
Lens	Motorised Optical 20x zoom, F2.8 to F4.5
Lens (Focal Length)	f = 8.8 mm to 176.0 mm
35 mm Equivalent Focal Length	24.5 mm to 490.0 mm
Conversion Lens	Not supported
Angle of View Range	Horizontal: 75.1° (wide) to 4.0° (tele)
Angle of View Range	Vertical: 46.7° (wide) to 2.3° (tele)
Angle of View Range	Diagonal: 82.8° (wide) to 4.6° (tele)
ND Filter	Through, 1/4, 1/16, 1/64, IR through (used as “Night mode”)
Focus	Switching between auto and manual
Focus Distance	Entire zoom range: 1000 mm (3.3 ft)
Focus Distance	Wide end: 100 mm (0.33 ft)
Colour Separation Optical System	1MOS
Standard Sensitivity	F9, 2000 lx
Minimum Illumination	2 lx (F2.8, 59.94p, 50IRE, 42 dB, without accumulation)
Horizontal Resolution	2,000 TV lines Typ (centre area)
Gain Selection	Auto, -3 dB to 36 dB (1 dB step increments)
Gain Selection	Super Gain: +37 dB to 42 dB
Frame Mix	0 dB, 6 dB, 12 dB, 18 dB, 24 dB
Electronic Shutter Speed (59.94p/59.94i)	1/60 to 1/10000
Electronic Shutter Speed (50p/50i)	1/60 to 1/10000
Electronic Shutter Speed (29.97p)	1/30 to 1/10000
Electronic Shutter Speed (25p)	1/25 to 1/10000
Electronic Shutter Speed (23.98p/24p)	1/24 to 1/10000
Synchro Scan (59.94p/59.94i)	60.00 Hz to 7200 Hz
Synchro Scan (50p/50i)	50.00 Hz to 7200 Hz
Synchro Scan (29.97p)	30.00 Hz to 7200 Hz
Synchro Scan (25p)	25.00 Hz to 7200 Hz
Synchro Scan (23.98p/24p)	24.00 Hz to 7200 Hz
Gamma	HD / FILMLIKE1 / FILMLIKE2 / FILMLIKE3 / FILM REC / VIDEO REC
White Balance	ATW: 3200K, 5600K (3-speed variable)
White Balance	AWB: AWB-A / AWB-B
White Balance	VAR: 2000K to 15000K
Chroma Amount Variability	OFF, –99 % to 99 %
Scene File	Scene1, Scene2, Scene3, Scene4
Output Format (UHD/FHD SDI) - 4K	2160/59.94p, 2160/50p, 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Native), 2160/23.98p (Native)
Output Format (UHD/FHD SDI) - HD	1080/59.94p, 1080/50p, 1080/29.97p (Native), 1080/25p (Native), 1080/24p (Native), 1080/23.98p (Native), 1080/59.94i, 1080/50i, 720/59.94p, 720/50p
Output Format (UHD/FHD Fibre) - 4K	2160/59.94p, 2160/50p, 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Native), 2160/23.98p (Native)
Output Format (UHD/FHD Fibre) - HD	1080/59.94p, 1080/50p, 1080/29.97p (Native), 1080/25p (Native), 1080/24p (Native), 1080/23.98p (Native), 1080/59.94i, 1080/50i, 720/59.94p, 720/50p
Camera Unit
Imaging Sensor	1-type 4K MOS x1
Effective Pixels	Approx. 20,180,000 pixels
Zoom	Optical zoom: 20x
Zoom	i.Zoom: UHD 24x, FHD 32x
Lens	Motorised Optical 20x zoom, F2.8 to F4.5
Lens (Focal Length)	f = 8.8 mm to 176.0 mm
35 mm Equivalent Focal Length	24.5 mm to 490.0 mm
Conversion Lens	Not supported
Angle of View Range	Horizontal: 75.1° (wide) to 4.0° (tele)
Angle of View Range	Vertical: 46.7° (wide) to 2.3° (tele)
Angle of View Range	Diagonal: 82.8° (wide) to 4.6° (tele)
ND Filter	Through, 1/4, 1/16, 1/64, IR through (used as “Night mode”)
Focus	Switching between auto and manual
Focus Distance	Entire zoom range: 1000 mm (3.3 ft)
Focus Distance	Wide end: 100 mm (0.33 ft)
Colour Separation Optical System	1MOS
Standard Sensitivity	F9, 2000 lx
Minimum Illumination	2 lx (F2.8, 59.94p, 50IRE, 42 dB, without accumulation)
Horizontal Resolution	2,000 TV lines Typ (centre area)
Gain Selection	Auto, -3 dB to 36 dB (1 dB step increments)
Gain Selection	Super Gain: +37 dB to 42 dB
Frame Mix	0 dB, 6 dB, 12 dB, 18 dB, 24 dB
Electronic Shutter Speed (59.94p/59.94i)	1/60 to 1/10000
Electronic Shutter Speed (50p/50i)	1/60 to 1/10000
Electronic Shutter Speed (29.97p)	1/30 to 1/10000
Electronic Shutter Speed (25p)	1/25 to 1/10000
Electronic Shutter Speed (23.98p/24p)	1/24 to 1/10000
Synchro Scan (59.94p/59.94i)	60.00 Hz to 7200 Hz
Synchro Scan (50p/50i)	50.00 Hz to 7200 Hz
Synchro Scan (29.97p)	30.00 Hz to 7200 Hz
Synchro Scan (25p)	25.00 Hz to 7200 Hz
Synchro Scan (23.98p/24p)	24.00 Hz to 7200 Hz
Gamma	HD / FILMLIKE1 / FILMLIKE2 / FILMLIKE3 / FILM REC / VIDEO REC
White Balance	ATW: 3200K, 5600K (3-speed variable)
White Balance	AWB: AWB-A / AWB-B
White Balance	VAR: 2000K to 15000K
Chroma Amount Variability	OFF, –99 % to 99 %
Scene File	Scene1, Scene2, Scene3, Scene4
Output Format (UHD/FHD SDI) - 4K	2160/59.94p, 2160/50p, 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Native), 2160/23.98p (Native)
Output Format (UHD/FHD SDI) - HD	1080/59.94p, 1080/50p, 1080/29.97p (Native), 1080/25p (Native), 1080/24p (Native), 1080/23.98p (Native), 1080/59.94i, 1080/50i, 720/59.94p, 720/50p
Output Format (UHD/FHD Fibre) - 4K	2160/59.94p, 2160/50p, 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Native), 2160/23.98p (Native)
Output Format (UHD/FHD Fibre) - HD	1080/59.94p, 1080/50p, 1080/29.97p (Native), 1080/25p (Native), 1080/24p (Native), 1080/23.98p (Native), 1080/59.94i, 1080/50i, 720/59.94p, 720/50p
Synchronization System	Internal/External synchronisation (BBS/Tri-level sync)
Input Connector
G/L IN	BBS (Black Burst Sync), tri-level sync supported
MIC/LINE Input	MIC/LINE input compatible (SDI/HDMI/IP) AAC compatible (IP only) ø3.5 mm stereo mini jack (unbalanced)
Output Connector
HDMI	HDMI 2.0 connector, 4:2:2/10 bit (HDCP and Viera Link not supported)
12G-SDI OUT	SMPTE 2082-1 / SMPTE 2081- 1 / SMPTE 424M / SMPTE 292M, 75 Ω (BNC×1)
3G-SDI OUT1	SMPTE 424M / SMPTE 292M, 75 Ω (BNC×1)
3G-SDI OUT2/PM	SMPTE 424M / SMPTE 292M, 75 Ω (BNC×1)
SFP+	SFP+ standard
Input/Output Connector
LAN	LAN connector for IP control (RJ‑45)
RS-422	CONTROL IN RS-422A (RJ‑45)
Pan-tilt Head Unit
IP Connecting Cable (PoE++ Hub)	max. 100 m (328 ft)
AW Protocol Connecting Cable	LAN cable max. 1000 m (3280 ft)
Installation Method	Stand-alone (Desktop) or suspended (Hanging
Pan/Tilt Operation Speed	0.08°/s to 180°/s (manual operation) 3 speed modes: Normal (60°/s), Fast1 (90°/s), Fast2 (180°/s); high speed operation noise caution
Panning Range	±175°
Tilting Range	–30° to 210° (camera may appear in image depending on position)
Quietness	NC35 or less (up to 60°/s in Normal mode)
Supported Operating Systems and Web Browsers
Windows	Microsoft® Windows® 10, Microsoft® Windows® 11, Microsoft Edge, Google Chrome
Mac	macOS 14, macOS 13, macOS 12, Safari, Google Chrome
iPhone/iPad	iOS, iPadOS, Safari
Android	Android OS, Google Chrome
IP Streaming
Image Streaming Mode	JPEG (MJPEG), H.264, H.265, NDI® HX2, NDI® High Bandwidth
Image Resolution	3840x2160, 1920x1080, 1280x720, 640x360, 320x180
JPEG Frame Rate	Maximum 30 fps
JPEG Image Quality	Fine / Normal
H.264 Transmission Type	Unicast port (AUTO), Unicast port (MANUAL), Multicast port
H.264 Transmission Mode	Constant bit rate, Frame rate, Best effort
H.264 Frame Rate (60Hz)	5fps / 15fps / 30fps / 60fps (UHD: 30fps, 60fps)
H.264 Frame Rate (50Hz)	5fps / 12.5fps / 25fps / 50fps (UHD: 25fps, 50fps)
H.264 Max Bit Rate	512kbps, 768kbps, 1024kbps, 1536kbps, 2048kbps, 3072kbps, 4096kbps, 6144kbps, 8192kbps, 10240kbps, 12288kbps, 14336kbps, 16384kbps, 20480kbps, 24576kbps, 32768kbps, 40960kbps, 51200kbps, 76800kbps
H.265 Transmission Type	Unicast port (AUTO), Unicast port (MANUAL), Multicast port
H.265 Frame Rate (60Hz)	30fps / 60fps
H.265 Frame Rate (50Hz)	25fps / 50fps
H.265 Max Bit Rate	512kbps, 768kbps, 1024kbps, 1536kbps, 2048kbps, 3072kbps, 4096kbps, 6144kbps, 8192kbps, 10240kbps, 12288kbps, 14336kbps
Audio Compression Format	AAC-LC, 48 kHz / 16 bit / 2ch
Supported Protocol (IPv6)	TCP/IP, UDP/IP, HTTP, HTTPS, DNS, NTP, SNMP, DHCPv6, RTP, MLD, ICMP, ARP, RTMP
Supported Protocol (IPv4)	TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP, RTMP, RTMPS, SRT
NDI® Support
NDI® Versions	NDI® HX2, NDI® High Bandwidth
Output Format 4K (High Bandwidth)	2160/59.94p, 2160/50p, 2160/29.97p, 2160/25p, 2160/24p, 2160/23.98p
Output Format HD (High Bandwidth)	1080/59.94p, 1080/50p, 1080/29.97p, 1080/25p, 1080/24p, 1080/23.98p, 720/59.94p, 720/50p
Image Resolution (HX2)	1920x1080, 1280x720
Transmission Type (High Bandwidth)	TCP/UDP, Unicast/Multicast
Max Bit Rate (High Bandwidth)	Max 250 Mbps
Transmission Type (HX2)	Unicast port (AUTO), Unicast port (MANUAL), Multicast port
Frame Rate (HX2, 60Hz)	5fps, 15fps, 30fps, 60fps (UHD: 30fps, 60fps)
Frame Rate (HX2, 50Hz)	5fps, 12.5fps, 25fps, 50fps (UHD: 25fps, 50fps)
Max Bit Rate (HX2)	512kbps, 768kbps, 1024kbps, 1536kbps, 2048kbps, 3072kbps, 4096kbps, 6144kbps, 8192kbps, 10240kbps, 12288kbps, 14336kbps, 16384kbps, 20480kbps, 24576kbps
Audio Compression Type (High Bandwidth)	AAC, 48 kHz, 2 ch
Audio Compression Type (HX2)	AAC-LC, 48 kHz, 16 bit, 2 ch
Other Function
Tally LED Display Colour	Red, Green, Yellow
Footnotes
1	Future support planned
2	This cannot be configured when the format is 2160/29.97p, 2160/23.98p, 2160/24p, 2160/25p, 1080/29.97p, 1080/25p.
3	When selecting formats for UHD SDI, HDMI, and Fiber, it is not possible to select different formats for each of them. Furthermore, the formats for FHD SDI and 3G SDI OUT2 are fixed to the formatting method selected for UHD SDI and HDMI.
4	Use of an STP (shielded twisted pair) cable is recommended.
5	Category 6 or more is used when sending 4K images.
