Blackmagic Design 2110 IP SDI to HDMI 12G-10

Categories: , SKU: BK-BMD-CONVNVIPM/12G/HDMI10 Tag:
Brand:

£834.00 £695.00 Ex. VAT

Pre-Order - Estimated Delivery Late June 2025

Description

Blackmagic Design 2110 IP SDI to HDMI 12G-10 (CONVNVIPM/12G/HDMI10) offers high quality conversion between all SD, HD and Ultra HD video standards, along with 3D LUTs for accurate calibration of HDMI displays. The device also features 10 independent XLR audio outputs with remote level control and customizable delay for sync with TVs and projectors. Additionally, it includes a front panel LCD with video, meters and menus, as well as a speaker and headphone connector.

Features:

  • Converts 12G-SDI or SMPTE-2110 IP video to HDMI
  • Supports all SD, HD, and Ultra HD formats
  • Rack mount design for professional installations
Comes With
  • 1x Blackmagic 2110 IP SDI to HDMI 12G-10
  • 1x Welcome wallet with QR code for software download

Additional information

BRAND

BLACKMAGIC

Delivery

Please note, for next-day shipping options the product must show in stock in the product status and be before the cut-off period. If the product does not show in stock most items will give an approximate lead time.

Collection
 Free Collection is available at our showroom in Hampton, please select this option at the payment stage at the checkout. Please allow one hour to pick and prepare your order for you so it is ready for you when you arrive. Collections must be made at our office during the hours of 9 am to 5:30 pm (Mon to Thurs) and 9 am to 5 pm (Friday).

Standard Delivery
Standard delivery costs £5.99 including VAT and will be sent out by Royal Mail or APC, this service can take 3-5 working days.

FREE UK Delivery On Orders Over £250
We offer FREE standard delivery on all orders over £250 Ex VAT to the UK mainland. Mon-Fri working days only. Saturday deliveries are not guaranteed.

Next Working Day Delivery
UK mainland orders placed before 2 pm will be dispatched the same day for next-day delivery. To qualify for next-day delivery orders must be placed before 2 pm Mon – Thur. Orders placed after 2 pm Thursday will be dispatched Friday for Monday delivery, excluding Bank Holidays. The charge for this service is £12.00 plus VAT. This service is only available for products that are in stock.

Saturday Delivery
Order before 2pm on Friday for Saturday deliveries. Saturday delivery cost £27.50 including VAT – this is only for the UK mainland.

*Excluding all Battery Generators*

Worldwide Shipping

At BPS we can arrange shipping worldwide on most of our products. Please contact sales@bps-tv.co.uk and provide details of the products you are interested in, billing and delivery address, and any company information. Our sales team will then arrange for a full quotation to be provided.

Specification

SDI Inputs1
SDI Loop Outputs1
SDI RatesSD, 1.5G, 3G, 6G and 12G
HDMI 2.0 Video Outputs1
SMPTE 2110 Input / Output1 x 10G Ethernet
SMPTE ST 2110 IP Audio Inputs / Outputs16 channels embedded input and output audio on ST‑2110 IP video via 10G Ethernet.
SDI Audio Inputs16 channels embedded audio.
SDI Audio Outputs16 channels embedded audio.
HDMI Audio Inputs8channels embedded audio.
HDMI Audio Outputs8 channels embedded audio.
Analog Audio Outputs10 channels of professional balanced analog audio with 3‑pin XLR connectors. 1 x 6.35 mm headphone jack.
Webcam Outputs1 x USB‑C up to 1080p60
EthernetEthernet supports 10/100/1000/10G BASE‑T for SMPTE 2110 IP video in and out, configuration and software updates.
Computer InterfaceUSB‑C for webcam out, updates and configuration
SD Video Standards525i59.94 NTSC, 625i50 PAL
HD Video Standards720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
2K Video Standards2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI, 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI
Ultra HD Video Standards2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60
4K Video Standards4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI
SMPTE ComplianceSMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2036‑1, SMPTE 2048‑1, SMPTE 2081‑10, SMPTE 2081‑11, SMPTE 2081‑12, SMPTE 2082‑10, SMPTE 2082‑11, SMPTE 2082‑12 and SMPTE ST2108‑1
SDI Metadata SupportRP 188/SMPTE 12M‑2 and closed captioning.
Audio SamplingTelevision standard sample rate of 48 kHz and 24 bit.
Color Precision8, 10 RGB 4:4:4 in all modes up to 1080p30 and 8, 10‑bit YUV 4:2:2 in all modes.
Color SpaceRec. 601, Rec. 709, Rec. 2020
HDMI HD Video Standards720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
HDMI Ultra HD Video Standards2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p62
HDMI 4K Video Standards4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI.
HDMI Color Precision4:2:2
HDMI Color SpaceYUV
