Bolin R9-420N NDI High Bandwidth 4K60 PTZ Camera – Black
£4,122.00 £3,435.00 Ex. VAT
Order Now Usually delivered in 3-5 days
Description
Bolin R9-420N NDI High Bandwidth 4K60 PTZ Camera (R9-420N) brings UHD 4K quality video to your production. This versatile PTZ camera outputs up to UHD 4K60 via 12G-SDI, HDMI, and IP streaming. It features a large 1/2.8″ CMOS sensor with 8.29MP image capture, a 20x optical zoom, an additional 16x digital zoom, a built-in tally light, and a wide 78.6° angle-of-view. This model also supports NDI transmission, which allows the camera to fit right into an existing NDI network, and it is NDI 6 ready.
The camera can output two simultaneous IP streams via NDI, RTP, RTMP, RTSP, or SRT using H.264, H.265, MJPEG formats, and streaming supports up to UHD 4K60. The camera can be controlled via the included IR remote or via IP using ONVIF or VISCA-over-IP, and via serial using VISCA, Pelco-P or Pelco-D, or via FreeD with an optional firmware upgrade. Audio can be embedded or de-embedded from the stream using the LEMO-type audio port. An optional fiber-based SDI module can be added using the SFP+ slot. The camera can be powered using PoE++ or via an optional power adapter.
Features
- On-screen character generator
- All firmware upgrade via IP
- Front and rear Tally Light
- POE++ and 12VDC/AC
- Built-in handle
- Genlock
- HDMI cable secure mount
Comes With
- x1 Bolin R9-420N NDI High Bandwidth 4K60 PTZ Camera – Black
- x1 Power Adapter
- x1 Power Cable
- x1 IR Remote Control
- x1 Safety Cable
- x1 RS-422/232 RJ45 Adapter
- x1 Dust Cover
- x1 Mounting Screw Set
- x1 Lens Cap
Additional information
| BRAND | Bolin |
|---|
Delivery
Please note, for next-day shipping options the product must show in stock in the product status and be before the cut-off period. If the product does not show in stock most items will give an approximate lead time.
Collection
Free Collection is available at our showroom in Hampton, please select this option at the payment stage at the checkout. Please allow one hour to pick and prepare your order for you so it is ready for you when you arrive. Collections must be made at our office during the hours of 9 am to 5:30 pm (Mon to Thurs) and 9 am to 5 pm (Friday).
Standard Delivery
Standard delivery costs £5.99 including VAT and will be sent out by Royal Mail or APC, this service can take 3-5 working days.
FREE UK Delivery On Orders Over £250
We offer FREE standard delivery on all orders over £250 Ex VAT to the UK mainland. Mon-Fri working days only. Saturday deliveries are not guaranteed.
Next Working Day Delivery
UK mainland orders placed before 2 pm will be dispatched the same day for next-day delivery. To qualify for next-day delivery orders must be placed before 2 pm Mon – Thur. Orders placed after 2 pm Thursday will be dispatched Friday for Monday delivery, excluding Bank Holidays. The charge for this service is £12.00 plus VAT. This service is only available for products that are in stock.
Saturday Delivery
Order before 2pm on Friday for Saturday deliveries. Saturday delivery cost £27.50 including VAT – this is only for the UK mainland.
*Excluding all Battery Generators*
Worldwide Shipping
At BPS we can arrange shipping worldwide on most of our products. Please contact sales@bps-tv.co.uk and provide details of the products you are interested in, billing and delivery address, and any company information. Our sales team will then arrange for a full quotation to be provided.
Specification
| Image Maker | Bolin |
|---|---|
| Image Sensor | IMX715, CMOS image sensor 1/2.8 type |
| Number of effective pixels | 8.29MP |
| Picture elements | 3840x2160 |
| Lens | 20X |
| Horizontal Angle of View | 78.59° (W)~4.92° (T) |
| Vertical Angle of View | 48.39° (W)~2.79° (T) |
| Focal Length | f= 3.55 mm (WIDE) to 63.58 mm (TELE) |
| Min. object distance | 50cm |
| Aperture | F2.0 (Wide) to F3.8 (Tele) |
| Min. Illumination | 0.5lux（color），0.1lux（black） |
| Shutter Speed | 1/1 sec to 1/10000 sec (28 steps) |
| Focus | Auto, Push, Manual |
| White Balance | Auto, Indoor, Outdoor,OPW,ATW, Manual |
| Exposure | Auto, Manual, Shutter /Iris /Brightness priority |
| Features | Backlight Compensation, E-FLIP, Mirror, Day/Night, Flicker ,Contrast, Effect, SHARPNESS |
| WDR | 120db |
| Image Stabilizer | Yes |
| Color Gain | Yes |
| Color Hue | Yes |
| Gamma | Yes |
