Eizo CG2400SV 24.1 Inch Monitor

Eizo CG2400SV 24.1 Inch Monitor

Eizo CG2400SV 24.1 Inch Monitor features SDI input and output terminals, supporting 3G-SDI Level A and HD-SDI signals. SDI connectivity enables the transmission of uncompressed video signals, preserving the full fidelity of HDR content without introducing visual artifacts. This ensures seamless integration with professional camera systems and live video feeds, making the monitor a reliable solution for accurate monitoring on-site and in-studio.

Flexible Connection, Sleek Cabinet Design

In addition to SDI, the CG2400SV includes DisplayPort^TM and HDMI^® terminals, as well as two USB Type-B inputs. Four USB ports (USB 5Gbps: Type A x 2, USB 2.0: Type-A x 2) are also easily accessible from the side for connecting additional devices or peripherals.

A sleek cabinet design with rounded edges and a non-intrusive stand base allows the monitor to fit comfortably in any creative environment, while a built-in carrying handle on the back provides a stable grip for smooth relocation or transportation.

Headphone Jack for Direct Audio Output

The CG2400SV features a headphone jack for conveniently checking audio content.

Industry Standard Color Reproduction with Broadcast and Cinema Presets

The monitor’s wide color gamut covers 98% of the DCI-P3 standard used in digital cinema and supports the BT.2020 standard used in broadcasting for exceptionally faithful reproduction of color. It also covers 99% of the Adobe RGB color space so images and video shot in Adobe RGB will be displayed correctly. Color mode presets can easily be changed via the switches on the front of the monitor, enabling straightforward color management for each project.

10-Bit Simultaneous Display

The monitor offers 10-bit simultaneous display* from a 16-bit look-up table (LUT), which means it can produce more than one billion colors. This is 64 times more colors than you get with 8-bit display, resulting in smooth color gradations and reduced Delta-E between two adjacent colors.

*A graphics board and software which support 10-bit output are also necessary for 10-bit display. Equipment that supports Deep Color is required for 10-bit display when connected via HDMI^® port.

3D LUT for Accurate Color Display

The monitor is equipped with a 3D LUT, which adjusts colors on an RGB cubic table. Using ColorNavigator 7’s LogView LUT Emulation function, users can emulate film color properties using a 3D LUT file.

・Japan patent no. 4808588

Built-In Sensor to Automate Your Workflow

The monitor’s built-in sensor can be set to calibrate the monitor automatically at designated times. This eliminates the need for a third-party calibration device and ensures your screen stays color-accurate. In addition, the sensor swings onto the screen, taking up minimal space and allowing you to continue working even during calibration.

・Japan patent no. 4809453
・EIZO does not recommend carrying out color-critical work during recalibration, as the screen’s colors will be adjusted.

ColorNavigator 7 Color Management Software

EIZO’s ColorNavigator Network provides centralized quality control of ColorEdge monitors for studios with multiple creators and editors working on shared projects. An administrator can set the color modes, schedule automatic self-calibration for monitors with built-in sensors, register or adjust asset management settings, and more – all carried out remotely over the network. For large-scale projects, this ensures that the appropriate color standards are used at every step and saves hundreds of hours spent on calibration and maintenance.

Summary

• Screen Size: 24.1 Inch
• Resolution: 1920 x 1200
• Inputs: HDMI
• Outputs: HDMI
