SmallHD Indie 7 On-Camera Monitor
£1,018.80 £849.00 Ex. VAT
Order Now - Usually delivered in 1-2 weeks
Description
SmallHD Indie 7 On-Camera Monitor – 7 INCH
SmallHD Indie 7 On-Camera Monitor (MON-INDIE-7) is the vivid, lightweight entry model into SmallHD’s professional 7-inch touchscreen monitor series. This hyperresponsive touchscreen monitor is powered by the user-customizable PageOS 4 software, with a host of internal imaging assistance tools such as Focus Assist, Exposure Assist, and more. Indie 7 provides a personalized viewing experience designed to improve your workflow. Backed by 1000nits of brightness for daylight visibility. Housed in a lightweight, rugged, and thin aluminum chassis designed for heavy production use.
Upgrade to Camera Control for RED® DSMC2® & KOMODO™*
Transform your touchscreen into the central command hub of your camera. SmallHD’s proprietary software enables unfettered access to RED® DSMC2® & KOMODO™ camera functions and project settings such as Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more. *Individual Camera Control software licenses are sold separately. Shop KOMODO. Shop DSMC2.
PageOS 4 Software Toolset
With the power of PageOS 4 software, utilize all of the dependable SmallHD internal toolset features such as customizable frame guides, Focus Assist, Exposure Assist, high-resolution 3D LUT overlays (via Full SD Card slot), histogram, vectorscope, waveform, and Teradek RT Overlays. Learn more about PagesOS 4
Compatible with Bolt RX Monitor Module
Improve your handheld monitoring workflow with this optional hardware addition to your Indie 7 monitor. Receive cable-free 4K and HDR wireless video from any Bolt 4K series transmitter at a distance of up to 750ft (228m). With 1:1 Pixel Mapping, utilize the added resolution to punch-in and achieve tack-sharp critical focus. Learn more about
Responsive Touchscreen with Daylight Visibility
- Full HD 7-inch IPS LCD with 1920×1200 resolution
- 10-bit color processing in 100% Rec 709
- 1000nits of brightness
- 4K & HDR compatible
- 160-degree viewing angle
Versatile I/O
- Input: 1x 3G-SDI, 1x 3G-SDI In/Out, 1x HDMI 2.0, 1x Micro USB
- Output: 1x 3G-SDI, 1x HDMI 2.0
Power Input Options
- 2mm barrel connector port
- Included Sony L-Series dual battery bracket
- Optional Gold Mount & V-Mount battery plate attachments (sold separately)
Rugged Lightweight Housing
- Anodized aluminum chassis
- Featherlight weight: 1.1lbs (.53kg)
- Ultrathin body width: 1.2in (3.35cm)
Comes With
- 1 x Indie 7 Monitor
- 1 x SmallHD Cleaning Cloth
- 1 x Sony L Series Battery Bracket
Additional information
| BRAND | SMALLHD |
|---|---|
| MPN | SHD-MON-INDIE-7 |
Delivery
Please note, for next-day shipping options the product must show in stock in the product status and be before the cut-off period. If the product does not show in stock most items will give an approximate lead time.
Collection
Free Collection is available at our showroom in Hampton, please select this option at the payment stage at the checkout. Please allow one hour to pick and prepare your order for you so it is ready for you when you arrive. Collections must be made at our office during the hours of 9 am to 5:30 pm (Mon to Thurs) and 9 am to 5 pm (Friday).
Standard Delivery
Standard delivery costs £5.99 including VAT and will be sent out by Royal Mail or APC, this service can take 3-5 working days.
FREE UK Delivery On Orders Over £250
We offer FREE standard delivery on all orders over £250 Ex VAT to the UK mainland. Mon-Fri working days only. Saturday deliveries are not guaranteed.
Next Working Day Delivery
UK mainland orders placed before 2 pm will be dispatched the same day for next-day delivery. To qualify for next-day delivery orders must be placed before 2 pm Mon – Thur. Orders placed after 2 pm Thursday will be dispatched Friday for Monday delivery, excluding Bank Holidays. The charge for this service is £12.00 plus VAT. This service is only available for products that are in stock.
Saturday Delivery
Order before 2pm on Friday for Saturday deliveries. Saturday delivery cost £27.50 including VAT – this is only for the UK mainland.
*Excluding all Battery Generators*
Worldwide Shipping
At BPS we can arrange shipping worldwide on most of our products. Please contact sales@bps-tv.co.uk and provide details of the products you are interested in, billing and delivery address, and any company information. Our sales team will then arrange for a full quotation to be provided.
Specification
| Environmental | |
| Item Weight (oz) | 18.9 |
| Package Weight (oz) | 26 |
| Height (in) | 4.67 |
| Width (in) | 1.32 |
| Length/Depth (in) | 7.09 |
| Compliance | FCC, IC, CE, RoHS |
| Operating Temperature | 30F to 100F |
| Storage Temperature | 0F to 120F |
| Mount Points | Four ¼-20 Mount Points (Left, Right, Bottom, and Back) |
| Construction | Anodized aluminium chassis |
| Display | |
| Panel Type | IPS LCD Touchscreen |
| Diagonal Size | 7.02 |
| Resolution | 1920x1200 |
| Pixel Density | 323 |
| Aspect Ratio | 0.6736111111111112 |
| Active Area | 5.95 x 3.72 |
| Brightness | 1000 Nits |
| Contrast | 1000:1 |
| Gamut | 100% rec709 |
| Colour Depth | 10-bit Processing (8-bit panel) |
| Viewing Angle | 160 |
| Backlight Type | LED |
| Adjustable Backlight | Yes |
| Input Signal | |
| 3G-SDI Input Types | YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100 |
| HD-SDI Input Types | YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98 |
| SD-SDI Input Types | YCC 4:2:2 @ 10-bits: 480i59.94, 576i50 |
| HDMI Input Types | YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 3840x2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50 |
| Audio Input Types | HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels |
| Output Signal | |
| 3G-SDI Output Types | YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100 |
| HD-SDI Output Types | YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98 |
| SD-SDI Output Types | YCC 4:2:2 @ 10-bits: 480i59.94, 576i50 |
| HDMI Output Types | YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 |
| Audio Output Types | HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection |
| Connector Type | |
| SDI | 1x BNC 3G input and 1x BNC 3G selectable input/output |
| HDMI | 1 input and 1 output: HDMI Type-D Receptacles (full size) |
| Audio | 1x 3.5mm 3-pin Stereo Headphone Jack |
| Power In | Barrel, 2.0mm ID, 5.5mm OD (center pin positive) |
| USB | 1x USB 2.0 Micro-B receptacle |
| Controls | |
| Primary | Touch Screen |
| Record Capture | Image Capture Tool |
| Power | |
| Connector | Barrel, 2.0mm ID, 5.5mm OD (center pin positive) |
| Voltage | DC in - 10V minimum to 34V maximum, Battery terminals – 6.0V minimum to 16.8V max |
| Consumption | 17.3 watts (2160p30, 100% bright, tools enabled), (2.4A @7.2V battery, 1.4A @12V barrel, 0.7A at 24V barrel) |
| Batter Plate Included | L-Series standard (V Mount or Gold Mount optional accessories) |
| Power Supply | Recommend DC 12~15V at ~2.5 amp or greater |
| Battery Types | L-Series, V Mount, Gold Mount |
| Overload Protection | DC input: Reverse polarity |
| Battery Chemistry | Li-ion |
| Battery Charging Time | Monitor does not support the charging of batteries |
| Software | |
| Pixel Zoom | 1.1-2.0x & 2.0-8.0x via swipe up/down. Infinitely adjustable via pinch & zoom |
| Frame Guides | Preset Aspect Ratios & Customizable |
| DSLR Scale | Canon 5DMkii & Canon 7D |
| Custom Scale | Yes (Underscan Only) |
| Anamorphic De-Squeeze | 0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x |
| Image Rotate | Automatic or Manual Control |
| Image Flip | Automatic or Manual Control |
| Cross Conversion | Yes: HDMI → SDI & SDI → HDMI |
| Focus Assist | User Adjustable Color Style and Intensity |
| Peaking | User Adjustable Intensity |
| False Colour | Rainbow, Arri Style, Custom with up to 10 nodes |
| Zebra | Dual - User Configurable |
| Waveform | Luma & RGB Style, Fully User Customizable w/ Region of Interest Highlighting |
| Vectorscope | Yes |
| RGB Parade | Fully User Customizable |
| Histogram | Luma & RGB Style |
| Image Capture | Yes |
| Custom LUTS | Loadable as Looks on Pages or as Systemwide Colour Calibration via the settings menu |
| LUT Downstream | Available on SDI or HDMI Out. Applied on Output Preview Page. |
| LUT Import | via SD Card or USB Storage Device |
| Overlay | With Opacity Slider and Blink Setting |
| Audio Meters | HDMI & SDI up to 8 channel |
